Portable AC charging pile test and measurement comprehensive instrument PEV7001
Portable AC charging pile test and measurement comprehensive instrument PEV7001

Portable AC charging pile test and measurement comprehensive instrument PEV7001

Skonda portable AC charging pile test and measurement comprehensive instrument PEV7001, with interoperability test and measurement verification function test. It is mainly used in the interoperability function verification, charging sequence working condition detection and metrological verification functions of newly installed AC charging piles, AC charging piles after maintenance, and upgraded AC charging piles. The comprehensive instrument has the characteristics of high accuracy, small size, light weight, and easy to carry. It can meet the measurement and performance testing of various occasions such as laboratory and on-site. The synthesizer has a metering module that meets the "JJG 1148-2018 Electric Vehicle AC Charging Pile" metering verification regulations, which can verify voltage error, current error, power error, working error, indication error, payment amount error, and clock indication error. The built-in software function module realizes the test items of "GB/T 34657.1-2017 Electric Vehicle Conductive Charging Interoperability Test Specification Part 1 Power Supply Equipment" and has two 63A standard charging gun sockets, and the pin definition meets GB/T 20234.2-2015 Stipulate the requirements.


◆   Features

01. The load is allowed to be connected to a real vehicle or any simulated load during measurement

02. With the function of detecting the ambient temperature, according to the actual working scene temperature, the error caused by the temperature is calculated, and the measurement result is judged

03. With GPS time synchronization function, it can test the Beijing time error of the charger

04. It has a charging sequence test interface, which can be connected to the emergency stop switch action and other pile end signals to meet the interoperability test specifications

05. With 16-channel timing synchronization measurement function, it can meet the related timing test of interoperability test, such as T1, T1, T2, T2, T3, T3, T3’’, T2-T2time, etc.

06. Built-in vehicle end R2 resistance, R3 resistance simulation equivalent resistance simulation function, R2 resistance adjustment range 500 Ω ~ 4000 Ω, the resistance value is continuously adjustable online, the adjustment fineness is 1 Ω, the nominal value of R3 equivalent resistance is 1400 Ω ~ 8000 Ω , The resistance value is continuously adjustable online, and the adjustment fineness is 1 Ω. Each contact has an on-off switch, which can simulate the on-off state of the contact

07. It has the function of measuring the voltage, current and CP signal of the AC charging pile

08. Built-in standard national standard test items, automatic test and report generation of the set-up procedure, to facilitate the change and upgrade of national standard items

09. The synthesizer has the function of test report generation template, which can generate test report format according to the customer's typesetting format. The report format can be TXT, EXECL, XLC, WORD

10. The test report supports a variety of data export methods: direct export via U disk, export via computer host computer via WIFI connection device, upload via 4G to the enterprise database platform

11. National standard test items, test function sub-modularity, network data interface, support for cross-platform calling 12. The input and output standard data structure of the test module of the integrated instrument software platform is convenient for analysis and calling

13. The synthesizer has a 10-inch high-definition LCD touch screen, which is convenient for users to touch and operate


◆   Applications
◆   Purchase information
◆   Technical Parameters
